Bio-Superlite
Extensive, thin, lightweight built-up green roof system
The lightest built-up assembly in the range, for decks with nothing left to give.
- Depth
- 2" (50 mm)
- Saturated load
- 11 lb/ft²
- Annual retention
- 45%
- Max slope
- to 2:12
- Wind
- CSA A123.24 tested assembly
- Fire
- ASTM E108 Class A
- Planting
- Pre-grown sedum mat, 10+ species
- Maintenance
- 2 visits/year
Retrofit over existing deckStormwater retention
Specified when
- Retrofit over existing structure
- Roofs at their load limit
- Green area ratio compliance
11 documents cover this system
DOCX
CSI 3-part specification — Bio-Superlite
DWG
Typical assembly details — all systems
DWG
Drain, penetration and expansion-joint details
PDF
Load table — saturated and dead loads, all systems
PDF
Wind resistance test report — CSA A123.24:21
PDF
Fire classification certificate — ASTM E108
Next system
Eco-Superlite
